Get these spectacular and high-performance Manual posi lock pullers from Pooja International that come with a range of innovative specs. Capacity depends on the model number and ranges from 1ton to 3 tons. The optimum reach, adjustable bolt diameters, unique spread range, and overall length makes it the best option for manufacturing units. Get the equipment today for heavy-duty pulling within the units. Our products come with warranties and can deliver outstanding performances.
| Model Number | Number of Jaws | Capacity Tons (kN) | Center Bolt Diameter A in. (mm) | ReachBin. (mm) | Spread Range C in. (mm) | Maximum Torque ft./lb. (N•m) | Weight lbs. (kg) | Overall Length in. (mm) |
|---|---|---|---|---|---|---|---|---|
| 202 | 2 | 1 ton (9 kN) | .31 in. (7.9 mm) | 2.25 in. (57 mm) | .25 to 3.25 in. (6.4 to 82.6 mm) | .62 lbs. (.28 kg) | 5.52 in. (140.2 mm) | |
| 102 | 3 | 1 ton (9 kN) | .31 in. (7.9 mm) | 2.25 in. (57 mm) | .25 to 3.25 in. (6.4 to 82.6 mm) | .68 lbs. (.31 kg) | 5.52 in. (140.2 mm) | |
| 203 | 2 | 2 tons (18 kN) | .37 in. (9.4 mm) | 3 in. (76.2 mm) | .25 to 4.5 in. (6.4 to 114.3 mm) | 1.12 lbs. (.51 kg) | 7 in. (177.8 mm) | |
| 103 | 3 | 2 tons (18 kN) | .37 in. (9.4 mm) | 3 in. (76.2 mm) | .25 to 4.5 in. (6.4 to 114.3 mm) | 1.3 lbs. (.59 kg) | 7 in. (177.8 mm) | |
| 204 | 2 | 2 tons (18 kN) | .5 in. (12.7 mm) | 4 in. (102 mm) | .5 to 5 in. (13 to 127 mm) | 20 ft./lb. (27 N•m) | 3.2 lbs. (1.5 kg) | 10.05 in. (255.3 mm) |
| 104 | 3 | 5 tons (44 kN) | .5 in. (12.7 mm) | 4 in. (102 mm) | .5 to 5 in. (13 to 127 mm) | 40 ft./lb. (54 N•m) | 4.1 lbs. (1.9 kg) | 10.05 in. (255.3 mm) |
| 206 | 2 | 6 tons (53 kN) | .62 in. (15.8 mm) | 6 in. (152 mm) | .5 to 7 in. (13 to 178 mm) | 75 ft./lb. (101 N•m) | 7 lbs. (3.2 kg) | 13.32 in. (338.3 mm) |
| 106 | 3 | 10 tons (89 kN) | .62 in. (15.8 mm) | 6 in. (152 mm) | .5 to 7 in. (13 to 178 mm) | 130 ft./lb. (176 N•m) | 8 lbs. (3.6 kg) | 13.32 in. (338.3 mm) |
| 208 | 2 | 12 tons (107 kN) | .75 in. (19 mm) | 8 in. (203 mm) | .75 to 12 in. (19 to 305 mm) | 150 ft./lb. (203 N•m) | 12 lbs. (5.4 kg) | 16.25 in. (412.8 mm) |
| 108 | 3 | 17 tons (151 kN) | .75 in. (19 mm) | 8 in. (203 mm) | .75 to 12 in. (19 to 305 mm) | 220 ft./lb. (297 N•m) | 14 lbs. (6.4 kg) | 16.25 in. (412.8 mm) |
| 210 | 2 | 14 tons (125 kN) | .75 in. (19 mm) | 9.67 in. (246 mm) | 1 to 15 in. (25 to 381 mm) | 175 ft./lb. (237 N•m) | 13 lbs. (5.9 kg) | 20.41 in. (518.4 mm) |
| 110 | 3 | 20 tons (178 kN) | .75 in. (19 mm) | 9.67 in. (246 mm) | 1 to 15 in. (25 to 381 mm) | 275 ft./lb. (372 N•m) | 16 lbs. (7.3 kg) | 20.41 in. (518.4 mm) |
| 213 | 2 | 25 tons (222 kN) | 1.12 in. (28.5 mm) | 12 in. (305 mm) | 2.5 to 18 in. (64 to 457 mm) | 475 ft./lb. (642 N•m) | 38 lbs. (17.3 kg) | 27.25 in. (692.2 mm) |
| 113 | 3 | 30 tons (267 kN) | 1.12 in. (28.5 mm) | 12 in. (305 mm) | 2.5 to 18 in. (64 to 457 mm) | 600 ft./lb. (811 N•m) | 44 lbs. (19.9 kg) | 27.25 in. (692.2 mm) |
| 216 | 2 | 35 tons (311 kN) | 1.25 in. (32 mm) | 14 in. (356 mm) | 3 to 25 in. (76 to 635 mm) | 800 ft./lb. (1,081 N•m) | 57 lbs. (25.9 kg) | 32.04 in. (813.8 mm) |
| 116 | 3 | 40 tons (356 kN) | 1.25 in. (32 mm) | 14 in. (356 mm) | 3 to 25 in. (76 to 635 mm) | 850 ft./lb. (1,149 N•m) | 68 lbs. (30.9 kg) | 32.04 in. (813.8 mm) |
